Hotspot finder, digital hotspot finder is an affordable, esay - to -use diagnostic tool that can precisely identify problem hot spots. Image hotspot finder's Two measurement cursors, movable anywhere in the image, can measure Temperature and Differential Temperature. The images can be Downloaded to PC with the supplied SD Card Reader or directly to a PC using the USB interface for Post Analysis.
How it works:
Just scan the target area and find the hottest spot on the screen. Place the hottest spot of your target on the center of the screen indicated by the circle (shown in picture below). It will also indicate the temperature of that spot. Then, simply press the laser button, and the laser will point to the hot spot on your target, corresponding to where it appears on the center of the screen. You can then take a thermal picture and store it in the Pocket PC. |
Features :-
Real Time Image and Temperature Measurement display
Crisp High Resolution Images
Large 3-1 2" LCD Display with LED backlight
Fully Radiometric - Measures the Temperature of every Pixel
Multiple Temperature Measurements
Stores up to 1000 Images with supplied SD Card
Image Browser with full image adjustment
Includes Operating Software, Wahl Easy Report1Software, SD Card & Card Reader
Lightweight * Simple Operation
Applications :-
ELECTRICAL :
* Loose or over tight connections
* Shorted or overloaded circuits
* Load imbalances
* Components which have failed or are fatigued such as fuses, circuit breakers, transformers, etc.
BUILDING INSPECTION :
* Detect improper or missing insulation
* Detect energy losses due to air leakage or conductive losses through walls
* Check central heating/cooling and underfloor heating systems
MECHANICAL :
* Improper lubrication of bearings and motors
* Misalignments in rotating equipment
* Improper tension in drive belts and pulleys
All these features and critical applications makes Hot Spot finder The Lowest Cost, High Performance, Thermal Imaging Camera in the Market! |
 |
Unique Mobile-like IR
Thermo raphic Camera :
The MoblR~ MB, representing a landmark of IR technology progress globally, is the latest
innovation from Guide Infrared who always works with innovative emotion. Guide presents MB
enriching the features exclusively for high-end IR camera before. 50Hz refresh rate? 2Mpixels
CMOS? Touch screen? Auto focus? IR video recording? Whatever you expect from a
thermographic camera, MB satisfies you by its compactness, ruggedization, accuracy,
efficiency, reliability, and affordability. |
Features and Benefits : |
Touch Screen
Operating it easily and do
I complicated analyses |
Infra Fusion
helping you identify where
the problem exactly is |
Auto Gate Technology
providing double
protection to the optics
and detectors
|
2.0 Megapixel CMOS
delivering extremely crisp
visual image |
Rugged Design
Magnalium housing is
more robust and shockresistant |
 |
Specifications |
|
| |
|
Imaging Performance |
Thermal |
|
| Detector Type |
Microbolometer UFPA 160x120 pixels, 25 µ m |
| Spectral range |
8-14 µ m |
| Field of view |
20.6 ° X 15.5 ° |
| Thermal Sensitivity |
<0.1 °C at 30 °C |
| Image Frequency |
50HZ PAL/60HZ NTSC |
| Visual |
|
| Built-in Digital Video |
CMOS Sensor, 1600x1200 pixels, 224 ture colors |
Image Presentation |
| External Dis lay |
2.47" TFT LCD with high resolution |
| Infra Fusion |
Visual and IR blending |
Measurement
|
| Temperature Range |
-20·C to 250 °C (350 °C/1200 °Coptional) |
| Accuracy |
+2°C or +2% of reading |
| Measurement Modes |
Auto hot & cold spot, auto alarm live/zoomed image & video;
spots, areas displaying either max, min or average, line profile,
histogram & isotherm band in live/frozen/saved image |
Storage
|
| Type |
Removable 2GB Mini SO card & built-in memory |
| Video Recording |
Recording up to 30 minutes in Mini SO card |
Laser Locator
|
| Classification Type |
Class 2 semiconductor laser |
Power System
|
| Battery Type |
Recharge Li-ion Camcorder battery, field-replaceable |
| Battery Operating Time |
4 hours continuous operation |
Environment
|
| Operating Temperature |
-10 °C to +60 °C |
| Temperature
Storage Temperature |
-20 °C to +60 °C |
Interface
|
| USB2.0 |
Real-time image, video data transfer to PC and real-time
control of the camera on PC |
| RS232 communication |
Control of camera on PC |
Interface
|
| Size |
154mmx69mmx45mm |
| Weight |
0.35kg |
| |
|
|
 |
